Wash and Dry Performance

The appliance offers an energy efficiency class of E for both wash and dry cycles and Eco 40–60 washing. Weighted energy consumption is 266 kWh per 100 complete Wash/Dry cycles and 77 kWh per 100 washing cycles in the Eco 40–60 programme. Water consumption is 68 litres per complete Wash/Dry cycle and 44 litres per Eco 40–60 wash cycle. Programme durations at rated capacity are 5:30 h:min for Wash and Dry and 2:50 h:min for wash only (Eco 40–60).

Wash Programmes and Drying

Available special wash programmes include:

• Easy-Care
• Night wash
• Mixed Load
• Sports wash
• Rapid 15
• Rinsing / Spinning
• Fluff clean
• Drain / Spin
• Allergy +
• Wool/handwash
• Delicates/Silk

A special drying programme is provided as a fluff removal cycle. The autoDry function and timed drying programmes allow selection of drying duration and level, as indicated on the display.

Controls and Display

Control is fully electronic via a control dial for all wash and special programmes, supported by dedicated buttons:

• Start
• Spin speed reduction
• Change
• Menu
• Drying time
• Temperature
• 24 hr Time Delay

The large display indicates programme progress, temperature, spin speed, time remaining, drying level and up to 24 hours time delay.

Safety and Protection Systems

• AquaStop system with lifetime warranty against water damage on this Neff home appliance.
• Foam detection system to monitor and respond to excessive suds.
• Safeguard monitoring system to adjust load distribution during spinning.
• Child safety lock to help prevent unintended changes to settings.
• Reload facility to allow interruption of the programme to add laundry (no further usage detail stated in source).
• Buzzer to signal the end of the programme.

Installation and Integration

The washer dryer is designed as a fully integratable built-in appliance. It features adjustable base height (16.5 cm) and adjustable base depth (6.5 cm) with height adjustment provided by a Cardan drive. Dimensioned drawings provide measurements in mm for fascia, housing and hinge cup hole depth of 13 mm with a 35 mm diameter and 24 mm setback. More specific installation instructions are Not stated in source.
