Which worktop depths are suitable for this kit?

The kit is suitable for kitchens with worktop depths of 60 cm or larger.

What components are included in the recirculation kit?

It includes a vertical 90° “S” bow flat duct element (male), three connector sleeves (female) to combine male flat duct elements, and a straight tube element (male, 500 mm).

What are the packed product dimensions and weight?

The packed product dimensions are 175x400x595 mm. The net weight is 2.6 kg and the gross weight is 3.7 kg.

How many Z861kR1 kits are standard on one pallet?

The standard number of units per pallet is 20, with pallet dimensions of 103.5 x 80.0 x 120.0.

Product Information Sheet

Neff Recirculation Kit

SKU: Z861KR1

Woodalls 1053–1055 Finchley Road, London, NW11 7ES
+44 (0)208 455 3925 · [email protected] · www.woodalls.co.uk

Mon–Fri: 9:00am – 5:00pm | Sat–Sun: Closed

Printed 19 July 2026

Neff Z861KR1 Recirculation Kit

SKU: Z861KR1 · EAN: 4242004264682

The Z861kR1 recirculation kit is an accessory set designed for partly ducted recirculation configurations of cooktops with an integrated ventilation module in kitchens with worktop depths of 60 cm or larger. Supplied as a dedicated kit of compatible duct elements and connector sleeves, it supports effective recirculation layouts where full ducting is not required, helping you complete the installation of your integrated ventilation solution.

2 Year Warranty

Enquire About This Product

All products are sold by enquiry. Add to your list and we'll be in touch.

Share This Product

This Product Page

Product name	ReciRculation kit Z861kR1
Configuration type	Accessory kit for partly ducted recirculation configurations
Compatible installation	Cooktop with integrated ventilation module
Suitable worktop depth	60 cm (or larger)
Kit contents	Vertical 90° “S” bow flat duct element (male); 3x connector sleeve (female) to combine male flat duct elements; straight tube element (male, 500 mm)
Dimensions of the packed product (H×W×D)	175x400x595 mm
Pallet dimensions	103.5 x 80.0 x 120.0
Standard number of units per pallet	20
Net weight	2.6 kg
Gross weight	3.7 kg
EAN code	4242004264682
