Siemens HZ9VDKE1 Accessories

SKU: HZ9VDKE1

The HZ9VDKE1 exhaust accessory starter kit is designed for ducted extraction configurations of cooktops with an integrated ventilation module in kitchens with worktop depths of 60 cm or larger. It includes high-performance, low-noise acoustic filters to significantly lower noise and improve psycho–acoustics, plus essential duct components for vertical 90° “S” bow connections and flat duct element combination.

2 Year Warranty

Enquire About This Product

All products are sold by enquiry. Add to your list and we'll be in touch.

Share This Product

This Product Page

Product name	Exhaust kit HZ9VDKE1
Type	Exhaust accessory starter kit for ducted extraction
Intended application	Cooktop with integrated ventilation module in ducted extraction configuration
Minimum worktop depth	60 cm or larger
Kit contents	4 acoustic filters, 1 vertical 90° “S” bow flat duct element (male), 1 connector sleeve (female)
Dimensions of packed product (H×W×D)	175x400x595 mm
Pallet dimensions	103.5 x 80.0 x 120.0
Standard number of units per pallet	20
Weight (net)	1.7 kg
Gross weight	2.6 kg
EAN code	4242003916124
