Neff I98WMM1Y7B N90 Flex Design Downdraft

SKU: I98WMM1Y7B · EAN: 4242004270799

Black - Choose Trims

The N 90 90 cm downdraft hood with Flex Design is a built–in glass draft hood that integrates behind the hob to create a single surface look. It uses Guided Air Technology and a climateControl Sensor for effective, fully automatic extraction. With clear glass panel illumination, touch control and powerful yet efficient BLDC motor technology, it is suitable for ducted extraction or recirculation in island or semi–island kitchens using electric hobs.

5 Year Warranty

Enquire About This Product

All products are sold by enquiry. Add to your list and we'll be in touch.

Share This Product

This Product Page

Product name	N 90 Downdraft Hood, 90 cm, Flex Design – i98WMM1Y7B
Typology	Downdraft
Width	90 cm wide
Installation typology	Built–in, integrated; suitable for installation in an island or semi–island kitchen solution; suitable for installation into 90 cm cabinet
Dimensions (HxWxD)	709 x 918 x 140 mm
Required niche size (HxWxD)	703 mm x 854.0 mm x 123 mm
Height of the appliance	709 mm
Net weight	40.8 kg
Control type	Electronic touch control; standard functions located on right–hand user interface
Speed settings	3–stage + 2 intensive; automatic revert; automatic intensive revert 6 mins; automatic after running 10 minutes
Maximum extraction rate (ducted)	519 m³/h (max. normal use); 833 m³/h (intensive)
Maximum extraction rate (recirculation with Clean Air Plus kit)	456 m³/h (max. normal use); 596 m³/h (intensive)
Maximum air flow	519 m³/h
Noise level (ducted)	Max. normal use: 62 dB(A) re 1 pW; Intensive: 71 dB(A) re 1 pW
Noise level (recirculation with Clean Air Plus kit)	Max. normal use: 66 dB(A) re 1 pW; Intensive: 71 dB(A) re 1 pW
Diameter of air outlet	150 mm; extractor hose 150 mm
Grease filter material	Washable stainless steel; 2 metal grease filter cassettes
Extension height	250 mm
Length of electrical supply cord	130 cm (1.3 m)
Connection rating	300 W
Energy efficiency class	A (range A+++ to D)
Average energy consumption	37.8 kWh/year*
Blower efficiency class	A*
Lighting efficiency class	-*
Grease filtering efficiency class	C*
Voltage	220–240 V
Frequency	50–60 Hz
Fuse protection	10 A
Plug type	GB plug
EAN code	4242004270799
Hob compatibility	Combination with gas hobs not possible
