Siemens HZ9VDKR1 Recirculation starter kit

SKU: HZ9VDKR1 · EAN: 4242003916100

The HZ9VDKR1 recirculation kit is a recirculation accessory kit designed for partly ducted configurations of a cooktop with integrated ventilation module. It is suitable for kitchens with worktop depths of 60 cm or larger. Supplied with vertical and straight duct elements plus connector sleeves, it supports effective recirculation installation where full ducting is not required.

2 Year Warranty

Enquire About This Product

All products are sold by enquiry. Add to your list and we'll be in touch.

Share This Product

This Product Page

Product name	Recirculation kit HZ9VDKR1
Type	Recirculation accessory kit partly ducted
Suitable worktop depth	60 cm (or larger)
Kit contents	Vertical 90° “S” bow flat duct element (male); 3x connector sleeve (female) to combine male flat duct elements; straight tube element (male, 500 mm)
Dimensions of packed product (H x W x D)	175x400x595 mm
Pallet dimensions	103.5 x 80.0 x 120.0
Standard number of units per pallet	20
Weight	2.3 kg
Gross weight	3.3 kg
EAN code	4242003916100
