Smeg KDD90CNE2 Downdraft

SKU: KDD90CNE2 · EAN: 8017709346126

Black Glass

The SMEG KDD90CNE2 is a fully integrated 90 cm downdraft cooker hood in black glass with a universal aesthetic. It offers ducted-out or recirculation extraction with perimeter extraction and touch controls. With four speeds including an intensive setting, LED lighting and an A class energy rating, it is designed to efficiently extract cooking vapours while integrating discreetly into the kitchen worktop.

2 Year Warranty

Enquire About This Product

All products are sold by enquiry. Add to your list and we'll be in touch.

Share This Product

This Product Page

Product family	Hood
Hood type	Downdraft Cooker Hoods
Design	Fully integrated
Extraction	Ducted out or re–circulation possible
Electronic control	Yes
Perimeter extraction	Yes
Material	Painted material
EAN code	8017709346126
Hood width	90 cm
Aesthetics	Universal
Colour	Black
Finishing	Glass
Glass type	Black
Serigraphy colour	Silver
Logo	Silk screen
Control setting	Touch control
Display	Digital
LED colour	White
Number of speeds	4
Intensive speed	Yes (Intensive/turbo setting)
24 h air filter function	Yes
Other functions	Delay_function, Time–setting options
Remote motor	KITRBDD – Kit Optional
Number of lights	1
Light type	LED
Light power	5 W
Light colour temperature scale	4000 K
Dimmer mode	Yes
Free outlet maximum capacity	740 m³/h
Motor power	250 W
Number of filters	2
Anti–grease filters	Aluminium
Filter replacement indicator	Yes (warning light to advise when filters need changing)
Vent outlet	150 mm
Remote control	Optional
Sliding door	Yes
Tube reduction	Yes
Annual Efficiency Consumption (AEChood)	57 kWh/year
Energy efficiency class (EEC)	A
Fluid Dynamic Efficiency (FDE)	29,30
Fluid Dynamic Efficiency class (FDEC)	A
Lighting Efficiency (LE)	40 lux/W
Lighting Efficiency Class (LEC)	A
Grease Filtering Efficiency (GFE)	65,1 %
Grease Filtering Efficiency Class (GFEC)	D
Air flow at minimum speed (Qmin)	200 m³/h
Maximum extraction rate	350 m³/h
Intensive extraction rate	720 m³/h
Airborne acoustical A–weighted sound power emission at minimum speed (SPEmin)	43 dBA
Airborne acoustical A–weighted sound power emission at maximum speed (SPEmax)	53 dBA
Airborne acoustical A–weighted sound power emission at boost speed (SPEboost)	68 dBA
Time increase factor (F)	0,9
Energy Efficiency Index per first cavity	53,1
Measured air flow rate at best efficiency point (Qbep)	398 m³/h
Measured air pressure at best efficiency point (Qbep)	429 Pa
Measured electric power input at best efficiency point (Wbep)	162 W
Normal power of the light system (Wl)	5 W
Average illumination of the light on the cooking surface (Emiddle)	200 lux
Sound power level at highest setting (Lwa)	49 dBA
Extraction rate IEC 61591 / Noise level IEC 60704–2–13	Speed 1: 200 m³/h – 43 dBA Speed 2: 280 m³/h – 49 dBA Speed 3: 350 m³/h – 53 dBA Speed 4: 440 m³/h – 57 dBA Intensive speed: 720 m³/h – 68 dBA
Nominal power	255 W
Voltage	220–240 V
Frequency (Hz)	50–60 Hz
Power supply cable length	1500 mm
Plug	(F;E) Schuko
Alternative colours available	White, Silver Glass
