How many burners does the hob have and what are their power levels?

The hob has four gas burners: a left front standard burner up to 1.75 kW, a left rear standard burner up to 1.75 kW, a right rear high–speed burner up to 3 kW and a right front economy burner up to 1 kW, depending on gas type.

What are the installation dimensions for this 60 cm gas hob?

The product dimensions are 56 x 590 x 520 mm (H x W x D). The required niche size for installation is 45 x 560–562 x 480–492 mm with a minimum worktop thickness of 30 mm.

Which gas types can this hob be used with?

It is usable for Nat gas L/LL G25/20 mbar (DE), NG H/E 20 mbar, E+ 20/25 mbar, Natural gas H 25 mbar (HU), Natural gas L 25 mbar (NL), Liquid gas G30,31 28–30/37 mbar, Liquid gas G30 37 mbar (PL) and Liquid gas 50 mbar. It is pre–set for natural gas.

Is a safety device included to stop gas flow if the flame goes out?

Yes. The hob includes a flame failure safety device which prevents unwanted gas flow when the flame goes out.

How is the flame ignited on this hob?

Ignition is via the control dials: you just push and turn the dials to ignite the flame.

Are there any optional accessories available?

Yes. Optional accessories listed are the HEZ298105 simmer plate and the HEZ298114 small pot support. Further accessory details are not stated in source.

Product Information Sheet

Bosch Serie 4 Gas Hob

SKU: PNP6B6B90

Woodalls 1053–1055 Finchley Road, London, NW11 7ES
+44 (0)208 455 3925 · [email protected] · www.woodalls.co.uk

Mon–Fri: 9:00am – 5:00pm | Sat–Sun: Closed

Printed 12 June 2026

Bosch PNP6B6B90 Serie 4 Gas Hob

SKU: PNP6B6B90 · EAN: 4242005134311

Tempered Black Glass

This Series 4 60 cm gas hob in black tempered glass is a built–in appliance with front–mounted, design co–ordinated sword knobs for convenient control of four gas burners. The frameless tempered glass surface can be installed flush or slightly raised on the worktop, while cast iron pan supports with rubber feet provide stable support. A flame failure safety device helps prevent unwanted gas flow when the flame goes out, and the hob is pre–set for natural gas with an LPG nozzle set included.

2 Year Warranty

Enquire About This Product

All products are sold by enquiry. Add to your list and we'll be in touch.

Share This Product

This Product Page

Model	PNP6B6B90
Series	Series 4
Appliance type	gas hob w integrated controls
Installation type	Built–in
Heating type	Gas
Number of cooking zones	4
Control setting devices	sword knobs
Location of control panel	Front
Basic surface material	Tempered glass
Colour of surface	Black
Colour of frame	Black
Hob dimensions (H x W x D)	45 x 590 x 520 mm
Dimensions of the product (H x W x D)	56 x 590 x 520 mm
Required niche size (H x W x D)	45 x 560–562 x 480–492 mm
Min. worktop thickness	30 mm
Width of the appliance	590 mm
Packed product dimensions (H x W x D)	141 x 651 x 578 mm
Net weight	13.1 kg
Gross weight	14.0 kg
Residual heat indicator	Without
Length of electrical supply cord	100 cm / Power cord: 1 m
Gas connection rating	7500 W
Connected load	7.5 kW
Voltage	220–240 V
Frequency	50; 60 Hz
Fuse protection	3 A
EAN code	4242005134311
Optional accessories	HEZ298105 Simmer plate; HEZ298114 Small pot support
