What is the maximum extraction rate of the Miele DA 2628?

The maximum air throughput is 640 m³/h in Booster level 1 according to EN 61591.

How many power levels does this extractor have?

It has three power levels plus one Booster level, all controlled electronically via light–touch switches with LEDs.

Are the grease filters dishwasher–safe?

Yes. The unit includes four 10–ply stainless steel grease filters that are dishwasher–safe, and there is a grease filter saturation indicator.

What are the installation height requirements above hobs?

The minimum height above electric hobs is 450 mm. Above gas hobs, the minimum safety distance is 650 mm for a maximum total power of 12.6 kW and burner power ≤ 4.5 kW.

Does the DA 2628 have energy–efficient lighting?

Yes. It features energy–efficient LED lighting with three 4.5 W lights, a lighting efficiency class of A, 700 lx light intensity and 3500 Kelvin colour temperature, plus a dimmer function.

Can this extractor connect to a smart hob?

The unit supports Miele@home and the Miele@mobile app, with the automatic Con@ctivity function. Combination with a WiFi–enabled Miele hob is recommended.

Product Information Sheet

Miele Canopy Hood

SKU: DA2628SS

Woodalls 1053–1055 Finchley Road, London, NW11 7ES
+44 (0)208 455 3925 · [email protected] · www.woodalls.co.uk

Mon–Fri: 9:00am – 5:00pm | Sat–Sun: Closed

Printed 11 June 2026

Miele DA2628SS Canopy Hood

SKU: DA2628SS · EAN: 4002516001515

Stainless Steel

The Miele DA 2628 is an integrated extractor unit designed for customised kitchen layouts, fully built in at 1180 mm width. It offers edge extraction and energy–efficient LED lighting, controlled via light–touch switches with LEDs. With Con@ctivity, Miele@home and the Miele@mobile app, it provides convenient automatic operation. A powerful ECO motor delivers up to 640 m³/h in Booster level with A+ energy efficiency and effective stainless steel grease filtration.

2 Year Warranty

Enquire About This Product

All products are sold by enquiry. Add to your list and we'll be in touch.

Share This Product

This Product Page

Product name	DA 2628 Extractor unit
Material number	10851370
EAN number	4002516001515
Construction type	Integrated extractor
Operating mode	Exhaust air, type of air guide: Exhaust air
Colour	Stainless steel
Edge extraction	Yes
Miele@home	Yes
Automatic function	Con@ctivity
Controls	Electronic light–touch switches with LEDs
Miele@mobile app	Supported
Power levels (without Booster)	3
Booster levels	1
Run–on time	5/15 min.
Grease filter saturation indicator	Yes
Energy efficiency class (A+++ – D)	A+
ECO motor	ECO motor (DC motor)
PowerManagement system	Yes
Annual energy consumption	26.8 kWh/year
Fluid dynamic efficiency class	A
Lighting efficiency class	A
Grease filtering efficiency class	A
Easy–to–clean canopy interior	CleanCover
Number of stainless steel grease filters	4 (10–ply, dishwasher–safe)
Lighting	3 × 4.5 W LEDs, 700 lx, 3500 Kelvin, dimmer function
Fan	Dual–action blower
Air throughput Level 1	200 m³/h according to EN 61591
Air throughput Level 2	300 m³/h according to EN 61591
Air throughput Level 3	400 m³/h according to EN 61591
Air throughput Booster level 1	640 m³/h according to EN 61591
Sound power Level 1	36.0 dB(A) re 1 pW according to EN 60704–3
Sound power Level 2	44.0 dB(A) re 1 pW according to EN 60704–3
Sound power Level 3	51.0 dB(A) re 1 pW according to EN 60704–3
Sound power Booster level 1	62.0 dB(A) re 1 pW according to EN 60704–3
Sound pressure Level 1	22.0 dB(A) re 20 µPa according to EN 60704–2–13
Sound pressure Level 2	30.0 dB(A) re 20 µPa according to EN 60704–2–13
Sound pressure Level 3	37.0 dB(A) re 20 µPa according to EN 60704–2–13
Sound pressure Booster level 1	48.0 dB(A) re 20 µPa according to EN 60704–2–13
Safety switch–off	Yes
Canopy width	1180 mm
Canopy height	63 mm
Canopy depth	293 mm
Net weight	15.0 kg
Length of supply lead	1.5 m
Standard plug fitted	Yes
Minimum height above electric hobs	450 mm
Minimum distance above gas hobs	650 mm (max. 12.6 kW total power, burner ≤ 4.5 kW)
Number of phases	1
Total rated load	0.09 kW
Voltage	230 V
Fuse rating	10 A
Frequency	50 Hz
Extraction ducting connection (top)	Yes
Extraction ducting connection (rear)	Yes
Diameter of exhaust duct	150 mm
Recommended combination	Combination with WiFi–enabled Miele hob recommended
Accessories included	Non–return flap
