Miele DA6698WOBBL Chimney Hood

SKU: DA6698WOBBL · EAN: 4002516585770

Obsidian Black

The Miele DA 6698 W Purist. Ed.6000 is a wall mounted cooker hood in obsidian black with energy-efficient LED lighting and electronic touch controls for simple operation. It offers powerful extraction up to 640 m³/h in Booster level, an ECO motor for efficient, quiet performance and a Miele Silence package. Designed to complement Miele built-in appliances, it features Con@ctivity automatic function and high grease, lighting and fluid dynamic efficiency classes.

2 Year Warranty

Enquire About This Product

All products are sold by enquiry. Add to your list and we'll be in touch.

Share This Product

This Product Page

Specification	Value
Product name	DA 6698 W Purist. Ed.6000 Wall mounted cooker hood
Material number	12050600
EAN number	4002516585770
Old material number	28669841GB
Construction type	Wall mounted cooker hood
Type of air guide	Can be retrofitted
Colour	Obsidian black
Automatic function	Con@ctivity
Electronic controls	Yes
Booster levels	1
Silence package	Yes
Energy efficiency class (A+++ – D)	A++
ECO motor	Yes
ECO motor type	DC motor
PowerManagement system	Yes
Annual energy consumption	24.6 kWh/year
Fluid dynamic efficiency class	A
Lighting efficiency class	A
Grease filtering efficiency class	A
Number of stainless steel grease filters	3 (dishwasher-safe, 10-ply)
Lighting	3 × 3 W LED
Light intensity	670 lx
Colour temperature	3500 Kelvin
Dual-action blower	Yes
Exhaust air throughput Level 1	200 m³/h (EN 61591)
Exhaust air throughput Level 2	300 m³/h (EN 61591)
Exhaust air throughput Level 3	400 m³/h (EN 61591)
Exhaust air throughput Booster level 1	640 m³/h (EN 61591)
Exhaust air sound power Level 1	36.0 dB(A) re 1 pW (EN 60704-3)
Exhaust air sound power Level 2	44.0 dB(A) re 1 pW (EN 60704-3)
Exhaust air sound power Level 3	52.0 dB(A) re 1 pW (EN 60704-3)
Exhaust air sound power Booster level 1	63.0 dB(A) re 1 pW (EN 60704-3)
Exhaust air sound pressure Level 1	21.0 dB(A) re 20 µPa (EN 60704-2-13)
Exhaust air sound pressure Level 2	29.0 dB(A) re 20 µPa (EN 60704-2-13)
Exhaust air sound pressure Level 3	37.0 dB(A) re 20 µPa (EN 60704-2-13)
Exhaust air sound pressure Booster level 1	48.0 dB(A) re 20 µPa (EN 60704-2-13)
Recirculation throughput Level 1	110 m³/h (EN 61591)
Recirculation throughput Level 2	185 m³/h (EN 61591)
Recirculation throughput Level 3	315 m³/h (EN 61591)
Recirculation throughput Booster level 1	460 m³/h (EN 61591)
Recirculation sound power Level 1	45.0 dB(A) re 1 pW (EN 60704-3)
Recirculation sound power Level 2	53.0 dB(A) re 1 pW (EN 60704-3)
Recirculation sound power Level 3	63.0 dB(A) re 1 pW (EN 60704-3)
Recirculation sound power Booster level 1	72.0 dB(A) re 1 pW (EN 60704-3)
Recirculation sound pressure Level 1	30.0 dB(A) re 20 µPa (EN 60704-2-13)
Recirculation sound pressure Level 2	38.0 dB(A) re 20 µPa (EN 60704-2-13)
Recirculation sound pressure Level 3	48.0 dB(A) re 20 µPa (EN 60704-2-13)
Recirculation sound pressure Booster level 1	57.0 dB(A) re 20 µPa (EN 60704-2-13)
Safety switch-off	Yes
Glass type	Single-ply safety glass (ESG)
Canopy width	898 mm
Canopy height	85 mm
Canopy depth	500 mm
Overall hood height for extraction mode and external	710–1030 mm
Overall height for vented and external (in.)	710 mm
Overall height for extraction mode and external mode cooker hoods	1030 mm
Overall height for recirculation mode cooker hoods	840–1160 mm
Overall height for recirculation (in.)	840 mm
Overall height for recirculation mode cooker hoods (max)	1160 mm
Net weight	26.0 kg
Length of supply lead	1.5 m
Standard plug fitted	Yes
Number of phases	1
Total rated load	0.08 kW
Voltage	230 V
Fuse rating	10 A
Frequency	50 Hz
Minimum height above electric hobs	450 mm
Minimum safety distance above gas hobs (max. 12.6 kW total power, burner ≤ 4.5 kW)	650 mm
Extraction ducting connection at top	Yes
Extraction ducting connection at rear	Yes
Diameter of exhaust duct	150 mm
Telescopic chimney	Yes
Accessories included	Non-return flap
