Smeg KSG6P4X Canopy Hood

SKU: KSG6P4X · EAN: 8017709319366

Stainless Steel

The SMEG KSG6P4X is a 60 cm fully integrated canopy cooker hood in brushed stainless steel with a universal aesthetic. It offers ducted out or re-circulation extraction, perimeter extraction and touch control with three speeds plus intensive. Two dimmable LED lights with adjustable colour temperature illuminate the cooking area, while aluminium anti-grease filters and filter replacement indicator support effective maintenance.

2 Year Warranty

Enquire About This Product

All products are sold by enquiry. Add to your list and we'll be in touch.

Share This Product

This Product Page

Product family	Hood
Hood type	Canopy Cooker Hoods
Design	Fully integrated
Extraction	Ducted out or re-circulation possible
Electronic control	Yes
Perimeter extraction	Yes
Material	Stainless steel
Type of steel	Brushed
EAN code	8017709319366
Model code	KSG6P4X
Hood width	60 cm
Aesthetics	Universal
Colour	Stainless steel
Finishing	Brushed
Logo	Silk screen
Control setting	Touch control back-lighted White
Led colour	White
No. of speeds	3 + Intensive speed
24h air filter function	Yes
Time-setting options	Switch off automatically (to run after end of cooking for a pre-set time and then switch off automatically)
Auto-Vent 2.0	Yes (connection between hob and hood)
No. of lights	2
Light type	LED
Light power	2,3 W
Dimmer mode	Yes
Light colour temperature range	2700 – 4000 K
Free outlet maximum capacity	730 m³/h
Motor power	230 W
No. of filters	2
Anti-grease filters	Aluminium
Filter replacement indicator	Yes
Vent outlet	150 mm
Minimum distance from GAS hob	650 mm
Minimum distance from ELECTRIC hob	650 mm
Non return valve	Yes
Annual Efficiency Consumption (AEChood)	58 kWh/year
Energy efficiency class (EEC)	B
Fluid Dynamic Efficiency (FDE)	27,9
Fluid Dynamic Efficiency class (FDEC)	B
Lighting Efficiency (LE)	39,3 lux/W
Lighting Efficiency Class (LEC)	A
Grease Filtering Efficiency (GFE)	74,9 %
Grease Filtering Efficiency Class (GFEC)	D
Air flow at minimum speed (Qmin)	265 m³/h
Maximum extraction rate	484 m³/h
Intensive extraction rate	660 m³/h
Airbourne acoustical A-weighted sound Power Emission at minimum speed (SPEmin)	49 dBA
Airborne acoustical A-weighted sound Power Emission at maximum speed (SPEmax)	62 dBA
Airbourne acoustical A-weighted sound power emission at boost speed (SPEboost)	67 dBA
Time increase factor (F)	1,0
Energy Efficiency Index per first cavity	58
Measured air flow rate at best efficiency point (Qbep)	348 m³/h
Measured air pressure at best efficiency point (Qbep)	433 Pa
Measured electric power input at best efficiency point (Wbep)	150 W
Normal Power of the light system (Wl)	5 W
Average illumination of the light on the cooking surface (Emiddle)	181 lux
Sound power level at highest setting (Lwa)	62 dBA
Nominal power	235 W
Voltage	220-240 V
Frequency (Hz)	50-60 Hz
Power supply cable length	1500 mm
Extraction rate IEC 61591 [m³/h] – Speed 1	265
Noise level IEC 60704-2-13 [dBA] – Speed 1	49
Extraction rate IEC 61591 [m³/h] – Speed 2	360
Noise level IEC 60704-2-13 [dBA] – Speed 2	56
Extraction rate IEC 61591 [m³/h] – Speed 3	484
Noise level IEC 60704-2-13 [dBA] – Speed 3	61
Extraction rate IEC 61591 [m³/h] – Intensive speed	660
Noise level IEC 60704-2-13 [dBA] – Intensive speed	67
