Can this hood be used with both ducted and recirculation setups?

Yes. The extraction type is stated as ducted out or re–circulation possible.

How many speeds does the SMEG KSG8P4X have?

It has 3 speeds plus an intensive speed for extra fast extraction when required (intensive/turbo setting: when extra fast extraction is required).

What are the minimum installation heights above the hob?

The minimum distance from a gas hob is 650 mm and the minimum distance from an electric hob is also 650 mm.

Does the hood indicate when filters need changing?

Yes. It has a filter replacement indicator and warning lights to advise when filters need changing (warning light(s): to advise when filters need changing).

What is the energy efficiency class of this hood?

The energy efficiency class (EEC) is A, with annual efficiency consumption of 53 kWh/year.

What compatible charcoal filters are available?

Compatible accessories include FLT6 round charcoal filters (kit 2 pieces) and KITALLFC universal charcoal filter Stainless Steel AISI 304.

Product Information Sheet

Smeg Canopy Hood

SKU: KSG8P4X

Woodalls 1053–1055 Finchley Road, London, NW11 7ES
+44 (0)208 455 3925 · [email protected] · www.woodalls.co.uk

Mon–Fri: 9:00am – 5:00pm | Sat–Sun: Closed

Printed 13 June 2026

Smeg KSG8P4X Canopy Hood

SKU: KSG8P4X · EAN: 8017709319373

Stainless Steel

The SMEG KSG8P4X is a 75 cm fully integrated canopy cooker hood in brushed stainless steel, designed for ducted or re–circulation extraction. With touch control back–lighted white controls, perimeter extraction and three speeds plus intensive, it offers flexible performance. LED lighting with dimmer mode illuminates the cooking area, while aluminium anti–grease filters and a filter replacement indicator support everyday use. It is suitable for installation above gas or electric hobs at 650 mm minimum distance.

2 Year Warranty

Enquire About This Product

All products are sold by enquiry. Add to your list and we'll be in touch.

Share This Product

This Product Page

Product family	Hood
Hood type	Canopy Cooker Hoods
Design	Fully integrated
Extraction	Ducted out or re–circulation possible
Electronic control	Yes
Perimeter extraction	Yes
Material	Stainless steel, brushed type of steel
EAN code	8017709319373
Hood width	75 cm
Aesthetics	Universal
Colour / finishing	Stainless steel, brushed finishing
Logo	Silk screen
Control setting	Touch control back–lighted white
Number of speeds	3 + intensive speed
24h air filter function	Yes
Time–setting options	Yes
Auto–Vent 2.0	Yes
Number of lights	2
Light type	LED
Light power	2.3 W
Dimmer mode	Yes
Light colour temperature range	2700 – 4000 K
Free outlet maximum capacity	730 m³/h
Motor power	230 W
Number of filters	2
Anti–grease filters	Aluminium
Filter replacement indicator	Yes
Vent outlet	150 mm
Minimum distance from gas hob	650 mm
Minimum distance from electric hob	650 mm
Non return valve	Yes
Annual efficiency consumption (AEChood)	53 kWh/year
Energy efficiency class (EEC)	A
Fluid Dynamic Efficiency (FDE)	29.7
Fluid Dynamic Efficiency class (FDEC)	A
Lighting Efficiency (LE)	38.0 lux/W
Lighting Efficiency Class (LEC)	A
Grease Filtering Efficiency (GFE)	73.8 %
Grease Filtering Efficiency Class (GFEC)	D
Air flow at minimum speed (Qmin)	266 m³/h
Maximum extraction rate	480 m³/h
Intensive extraction rate	681 m³/h
Sound power emission at minimum speed (SPEmin)	46 dBA
Sound power emission at maximum speed (SPEmax)	60 dBA
Sound power emission at boost speed (SPEboost)	67 dBA
Time increase factor (F)	0.9
Energy Efficiency Index per first cavity	52.5
Measured air flow rate at best efficiency point (Qbep)	356 m³/h
Measured air pressure at best efficiency point (Qbep)	448 Pa
Measured electric power input at best efficiency point (Wbep)	149 W
Normal power of the light system (Wl)	5 W
Average illumination on cooking surface (Emiddle)	175 lux
Sound power level at highest setting (Lwa)	60 dBA
Nominal power	235 W
Voltage	220–240 V
Frequency (Hz)	50–60 Hz
Power supply cable length	1500 mm
Extraction rate IEC 61591 & Noise level IEC 60704–2–13	Speed 1: 266 m³/h, 46 dBA Speed 2: 356 m³/h, 52 dBA Speed 3: 480 m³/h, 60 dBA Intensive speed: 681 m³/h, 67 dBA
Overall width (drawing)	747 mm
Overall depth (drawing)	280 mm
Overall height (drawing, side view)	270 mm
Internal width between mounting points (drawing)	709 mm
Central section width (drawing)	570 mm
